Dixon Valve & Coupling Company
Dixon GLSC445 Gauge, 2-1/2 in Dial, 0 to 2000 psi, 1/4 in NPT Center Back Mount, 50 psi, +/-3-2-3%
DIXVAL GLSC445
$40.43
/ EA
Out of Stock
- Accuracy: +/-3-2-3%
- Case Material: ABS
- Connection Type: 1/4 in NPT Center Back Mount
- Dial: 2-1/2 Inch
- Graduations: 50 PSI
- Lens Material: Polycarbonate
- Liquid Filled: Glycerine
- Measuring Range: 0 to 2000 PSI
- Temperature Rating: -4 to 140 Degree F
- Tube Material: Copper Alloy
- Warranty: Limited
- 500 Hg/psi figure interval
- PowerFlex™ movement with polyester segment, designed to resist the effects of shock, vibration and pulsation
- White aluminum dial with black numbers and black aluminum pointer
- Copper alloy bourdon tube
- Warning: This product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
Application:
All of the gauges supplied by Dixon are designed for long, reliable service under rugged conditions. Typical applications include those on pumps, hydraulic and pneumatic systems, compressors, machine tools and many other installations where it is necessary to have a gauge with a non-corrosive movement
Dixon Gauge | 2-1/2 in Dial | 0 to 2000 psi | 1/4 in NPT Center Back Mount Connection | Graduations: 50 psi | +/-3-2-3% Accuracy | Liquid Filled: Glycerine | ABS Case | Copper Alloy Tube | Polycarbonate Lens | -4 to 140 deg F
