SGS® 3CR Corner Radius Center Cutting General Purpose End Mill, 3 in OAL, 2 Flutes, 1/2 in Cutter, 1 in, 1/2 in Shank
SGS 38267
$105.59
/ EA
Out of Stock
- Corner Radius: 0.06 in
- Diameter - Fractional: 1/2 in
- End Type: Corner Radius
- Flute Type: Spiral
- Helix Angle: 30 deg
- Overall Length: 3 in
- Series: 03C
- Shank Diameter - Fractional: 1/2 in
- Shank Length: 2 in
- Diameter - Metric: 12.7 mm
- Diameter - Decimal: 0.5 in
- Type: Finishing
- Shank Diameter - Metric: 12.7 mm
- Material: Carbide
- Shank Diameter - Decimal: 0.5 in
- Finish: Uncoated
SGS general purpose end mills are manufactured to the highest standards on state of the art CNC equipment. Held to the same standard as high performance product, the SGS general purpose end mill delivers consistent dependable performance beyond a typical general purpose end mill.
- Solid carbide provides better rigidity than high speed steel
- It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials
- Lab inspected and certified raw material
- Precision CNC ground to industry leading specifications
- Consistent quality and predictable performance
- Positive rake angle
- External coolant
- Applicable materials: steels, stainless steels, cast iron, high temp alloys, titanium, non-ferrous and plastic/composites
- +0.000/-0.002 in D1, H6 D2 tolerances, +0.000/-0.002 corner radius tolerances
- 0.06 in corner radius
Application: Aerospace, Medical, Power Generation, Automotive, Castings, Foundries, General Engineering, Mold and Die
SGS® End Mill | Corner Radius Center Cutting General Purpose Medium Length Single End | Series: 3CR | 1/2 in Cutter Dia | 3 in Overall Length | 1 in Maximum Depth of Cut | 2 Flutes | Spiral Flute | 1/2 in Shank Dia | Right Hand Cutting | 30 deg Helix Angle | Straight/Weldon Flat Shank | Micrograin Solid Carbide | Uncoated
