Dixon Valve & Coupling Company
Dixon D2M3-B Interchange Plug, 3/8-18, MNPTF, Brass
DIXVAL D2M3-B
$4.10
/ EA
Out of Stock
- End Type: MNPTF
- Fitting/Connector Type: Plug
- Hex Size: 3/4 in
- Length: 1-3/4 in
- Material: Brass
- Nominal Size: 3/8/2018
- Series: DF
- Temperature Rating: -40 to 250 deg F
- Machined components are manufactured using solid bar stock
- Rated pressure when connected with brass D-series automatic couplers: 500 psi (35 bar) maximum working and 16,000 psi (1,100 bar) burst
- Rated pressure when connected with brass F-series manual couplers: 300 psi (20 bar) maximum working and 8500 psi (586 bar) burst
- Compatible with Foster 3, 4, 5 and 6 series, Parker 30 - series automatic interchange & Parker 20 series manual interchange and Hansen 3000, 4000, 5000 and 6000 & Hansen 1000, 400 and 500
- 0.79 in OD max
- 1/4 in body
Application:
Industrial
Dixon Interchange Plug | Series: DF | 3/8-18 Nominal | MNPTF | 3/4 in Hex | 1-3/4 in L | Brass | -40 to 250 deg F
