Seco 02636652 Parting-Off Insert, ANSI Code: 150.10-4N-16 TGP45, 4 150.10 Insert, Material Grade: P, 4.1 mm W Cutting, 0 deg Lead Angle, Neutral Lead Angle Direction, Carbide, Manufacturer's Grade: TGP45, CVD-TiCN+Al2O3 Coated
SECO 02636652
$27.90
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Material: Carbide
- Insert Style: 150.10
- Insert Size: 4
- Lead Angle Direction: Neutral
- Lead Angle: 0 Degree
- Material Grade: P
- Manufacturer's Grade: TGP45
- Chipbreaker: 16
- Coating: TiCN+Al2O3
- Coating Process: CVD
- Corner Radius: 0.2 in
- Cutting Width: 4.100 mm
- Cutting Width - Metric: 4.1 mm
- Hand of Insert: Neutral
- Insert Hand: Neutral
- Manufacturer Grade: TGP45
- Overall Length: 9.000 mm
- Overall Width: 4.100 mm
- Part Number: 42560
- Relief Angle: 0 Degree
- Width - Metric: 4.1 mm
- Wear resistant Duratomic® CVD-coated grade intended for parting off of steel and stainless steel at moderate to high cutting speeds
Seco Parting-Off Insert | 150.10 Insert | 4 Insert | 4.1 mm Cutting Width | 0 deg Lead Angle | Neutral Lead Angle Direction | 4.1 mm Width | 9 mm Length | 16 Chipbreaker | 0.2 mm Corner Radius | Manufacturer's Grade: TGP45 | ANSI Code: 150.10-4N-16 TGP45 | Neutral Hand of Insert | Carbide | CVD-TiCN+Al2O3 Coated | Material Grade: P
