Seco 74001967 Parting-Off Insert, ANSI Code: 150.10-2.5N-12 T25M, 2.5 150.10 Insert, Material Grade: M, P, 2.5 mm W Cutting, Neutral Lead Angle Direction, 0 deg Relief Angle, Carbide, Manufacturer's Grade: T25M, CVD-TiC+TiCN+TiN Coated
SECO 74001967
$25.72
/ EA
Out of Stock
- Finish/Coating: CVD-TiC+TiCN+TiN Coated
- Material: Carbide
- Insert Style: 150.10
- Insert Size: 2.5
- Lead Angle Direction: Neutral
- Lead Angle: 0 Degree
- Material Grade: M, P
- Manufacturer's Grade: T25M
- Chipbreaker: 12
- Coating: TiC+TiCN+TiN
- Coating Process: CVD
- Corner Radius: 0.2 in
- Cutting Width: 2.500 mm
- Cutting Width - Metric: 2.5 mm
- Hand of Insert: Neutral
- Insert Hand: Neutral
- Manufacturer Grade: T25M
- Overall Width: 2.500 mm
- Part Number: 01967
- Relief Angle: 0 Degree
- Width - Metric: 2.5 mm
- Tough versatile CVD-coated grade intended for parting off of steel, stainless steel and cast iron at moderate cutting speeds
Seco Parting-Off Insert | 150.10 Insert | 2.5 Insert | 2.5 mm Cutting Width | Neutral Lead Angle Direction | 0 deg Relief Angle | 2.5 mm Width | 9 mm Length | 12 Chipbreaker | 0.2 mm Corner Radius | Manufacturer's Grade: T25M | ANSI Code: 150.10-2.5N-12 T25M | Neutral Hand of Insert | Carbide | CVD-TiC+TiCN+TiN Coated | Material Grade: M | P
