Seco 02949647 Single Sided Insert Indexable Copy Mill With Through Coolant Supply, ANSI Code: R220.29I-03.00-06-6A, R220.29 Toolholder
SECO 02949647
$1,155.60
/ EA
Out of Stock
- Cutting Diameter: 76.2 mm
- Cutting Diameter - Metric: 76.2 mm
- Maximum Depth of Cut: 6 in
- Shank Type: Arbor
- Shank Diameter: 62 mm
- Shank Diameter - Metric: 62 mm
- Cutting Direction: Right Hand
- Maximum Cutting Diameter: 76.2 mm
- Maximum RPM: 10000 RPM
- Minimum Cutting Diameter: 64.2 mm
- Number of Inserts: 6
- Overall Length: 50.8 mm
- Overall Length - Metric: 50.8 mm
- Part Number: 13721
- Toolholder Type: R220.29
- Our comprehensive range of round insert cutters, R217/220.29, is ideal for semi-finishing and roughing in all copy milling applications and materials
For general copy milling applications
Seco Indexable Copy Mill | Single Sided Insert | 76.2 mm Diameter Cutting | 50.8 mm Overall Length | 6 mm Maximum Depth of Cut | 6 Inserts | Insert Compatibility: RP..12 | 62 mm Shank Diameter | Arbor Shank | Right Hand Cutting Direction | ANSI Code: R220.29I-03.00-06-6A | ISO Code: R220.29I-03.00-06.6A | R220.29 Toolholder
