Mitutoyo 146-223 Metric Groove Micrometer, 25 to 50 mm Measuring, Graduations 0.01 mm

MITAME 146-223
$622.00 / EA
Out of Stock
Image for MITAME 146-223
  • Graduation: 0.01 mm
  • Graduations: 0.01 mm
  • Range: 25 - 50 mm / 26.35 - 51.5 mm
  • Flanged spindle and anvil for measuring width and location of grooves inside bores and tubes
  • Dual scales for direct reading of inside and outside measurements
  • Two-directional ratchet stop
  • Metric only model. Imperial model available (146-134), please contact us for details

Application:

  • This Internal Groove Micrometer is designed to measure the width and location of grooves cut into bore walls.

    • Mitutoyo 146-223 Max. Inside - 51.50 mm | Max. Outside - 50.00 mm | ± 0.01 mm Accuracy | Groove Micrometer
