Emuge CU456011.5018 Rekord 2D-TI CU456011 Form C Slow Reduced Shank Spiral Flute Tap, Right Hand Cutting, 1-8 Thread, Modified Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, NT2 Coated, HSS-E

• Rekord D-TI tap is a slow spiral design for blind holes, especially automatic lathes and multi-spindle machines
• Best suited for titanium and high tensile strength materials
• Taps are manufactured to produce a 3B tolerance thread form
• NT2 surface treatment - nitriding and oxidation - the surface of the tools is first nitrided and then oxidized (NT + NE2)
• This treatment combines increased surface hardness with an improved lubricant holding capacity
• TiCN coating option for additional wear resistance and extended tool life
• DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks

Standards/Approvals: DIN/ANSI Standard|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer

Emuge Spiral Flute Tap | Form C Slow Reduced Shank | Series: Rekord 2D-TI CU456011 | Measurement System: Imperial | UNC | 1-8 | Modified Bottoming Chamfer | 3 Flutes | HSS-E | NT2 Coated | Class of Fit: 3BX | Right Hand Cutting | 1.417 in Thread Length | 6.299 in Overall Length | 0.8 in Shank Dia | Right Hand Flute Direction
