Emuge CU459611.5015 Rekord 2D-TI CU459611 Form C Slow Reduced Shank Spiral Flute Tap, Right Hand Cutting, 5/8-11 Thread, Modified Bottoming Chamfer, Right Hand Flute Direction, 3 Flutes, TiCN Coated, HSS-E
EMUGE CU459611.5015
$189.82
/ EA
Out of Stock
- Coolant Through: No
- Thread Size: 5/8-11
- Material: HSS-E
- Finish/Coating: TiCN Coated
- Number of Flutes: 3
- Flute Direction: Right Hand
- Class of Fit: 3BX
- Chamfer Type: Modified Bottoming
- Cutting Direction: Right Hand
- Overall Length: 4.331 in
- Series: Rekord 2D-TI CU459611
- Shank Diameter: 0.48 in
- Shank Length: 3.268 in
- Thread Length: 1.063 in
- Thread Standard: UNC
- Rekord D-TI tap is a slow spiral design for blind holes, especially automatic lathes and multi-spindle machines
- Best suited for titanium and high tensile strength materials
- Taps are manufactured to produce a 3B tolerance thread form
- NT2 surface treatment - nitriding and oxidation - the surface of the tools is first nitrided and then oxidized (NT + NE2)
- This treatment combines increased surface hardness with an improved lubricant holding capacity
- TiCN coating option for additional wear resistance and extended tool life
- DIN/ANSI taps made with Emuge trademark long shanks - DIN length for extra reach and ANSI shanks
Standards/Approvals: DIN/ANSI Standard|ASME B1.1|PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer
Emuge Spiral Flute Tap | Form C Slow Reduced Shank | Series: Rekord 2D-TI CU459611 | Measurement System: Imperial | UNC | 5/8-11 | Modified Bottoming Chamfer | 3 Flutes | HSS-E | TiCN Coated | Class of Fit: 3BX | Right Hand Cutting | 1.063 in Thread Length | 4.331 in Overall Length | 0.48 in Shank Dia | 3.268 in Shank Length | Right Hand Flute Direction
