EXOCARB® 3190300 319 Straight Flute Hand Tap, Right Hand Cutting, #10-24 Thread, Bottoming Chamfer, 3 Flutes, Bright, Carbide
OSG 3190300
$154.37
/ EA
Out of Stock
- Coolant Through: No
- Thread Size: #10-24
- Material: Carbide
- Finish/Coating: Bright
- Number of Flutes: 3
- Class of Fit: 2B
- Chamfer Type: Bottoming
- Cutting Direction: Right Hand
- Flute Type: Straight
- Material Application: Aluminum, Cast Aluminum and Cast Iron
- Measurement System: Imperial
- Overall Length: 2.755 in
- Overall Length - Metric: 70 mm
- Series: 319
- Thread Standard: UNC
- Shank Diameter - Decimal: 0.194 in
- Finish: Bright
Standards/Approvals: DIN Rated
For general machine tapping, hand and power tapping for through or blind holes
EXOCARB Straight Flute Hand Tap | Series: 319 | Measurement System: Imperial | UNC | #10-24 | Bottoming Chamfer | 3 Flutes | Carbide | Bright | Class of Fit: 2B | Right Hand Cutting | 7/8 in Thread Length | 70 mm Overall Length | 0.194 in Shank Dia | Aluminum | Cast Aluminum and Cast Iron Material Application
