Emuge GF732257.0100 ZBGF-W Style Single Plane One Pitch Spiral Flute Thread Mill With Axial Through Coolant, M10x1.5, M12x1.5 Coarse/Fine Thread, 76 mm OAL, 4 Flutes, 10 mm Dia Shank
EMUGE GF732257.0100
$794.94
/ EA
Out of Stock
- Cutting Diameter - Metric: 7.75 mm
- Shank Diameter - Metric: 10 mm
- Shank Length: 1.5748 in
- Thread Size: M10x1.5, M12x1.5
- Number of Flutes: 4
- Finish/Coating: TiAlN-T4 Coated
- Material: Carbide
- Thread Type: Coarse/Fine
- Length of Cut - Metric: 6.9 mm
- Overall Length - Metric: 76 mm
- Series: GF732257
- Shank Type: Weldon Flat
- ZGBF-W 2XD style circular drill/thread mill for free machining materials
- Coolant fed for efficient chip evacuation
- Multi-layer TiAlN-T4 coated for heat and wear resistance
Standards/Approvals: PROP65: This product contains Cobalt, a chemical known to the State of California to cause cancer
For blind and through hole applications
Emuge Spiral Flute Thread Mill | ZBGF-W Style Single Plane One Pitch | Series: GF732257 | M10x1.5 | M12x1.5 | Coarse/Fine | 7.75 mm Cutting Dia | 6.9 mm Length of Cut | 76 mm Overall Length | 4 Flutes | Weld-On Flat Shank | 10 mm Shank Dia | 1.5748 in Shank Length | Carbide | TiAlN-T4 Coated
