Techniks 255032 32.00 mm, 81.00 mm, 72.00 mm, Hydraulic Tool Holder & Chuck
TECHNK 255032
$480.06
/ EA
Out of Stock
- Nose Diameter - Metric: 72 mm
- Body Diameter - Metric: 72 mm
- Bore Depth - Metric: 48 mm
- Bore Diameter - Metric: 32 mm
- Nose Length - Metric: 61.9 mm
- Overall Diameter - Metric: 69.85 mm
- Overall Length - Metric: 182.6 mm
- Projection Length - Metric: 81 mm
- Taper: CAT50
- Weight: 6.9
The NEW Triton Chucks by Techniks harness the full power of hydraulic technology to provide unmatched holding power and accuracy.Triton chucks are charged with hydraulic fluid in a vacuum chamber to eliminate air and gas from the system. Coupled with a redesigned oil sealing system, Triton chucks are built to provide maximum holding power for years. Use reduction sleeves to hold any shank diameter. Our H-LOCKED reduction sleeves are manufactured with patented TTG-594 for unmatched holding power.
- Newly designed hydraulic system provides 3.5X clamping force of standard hydraulic chucks
- Bore wall thickness increased 25% vs. standard hydraulic holders for improved rigidity in heavy stock removal applications
- Excellent vibration damping properties enhances surface finishes and extends tool life
Techniks 255032 32.00 mm | 81.00 mm | 72.00 mm | 72.00 mm | Hydraulic Tool Holder & Chuck
