OSG 1615012141 Thread Size M12x1.50, Thread Limit D11, Chamfer 4.5P, Thread Forming Tap
OSG 1615012141
$143.73
/ EA
Out of Stock
- Thread Size: M12-1.5
- Overall Length: 100.00 mm
- Thread Standard: Metric
- Finish/Coating: V-Coated
- Material: HSS-CO
- Chamfer Type: 4.5P Plug
- Class of Fit: 6H
- Measurement System: Metric
- Overall Length - Metric: 100 mm
- Series: 16150
- Shank Diameter - Decimal: 9.32 mm
- Square Size: 11.1 mm L x 6.98 mm W
- Thread Length: 1-21/32 in
- Thread Length - Metric: 17 mm
- Thread Limit: D11
The EXOPRO® XPF & S-XPF represent a new evolution in forming tap technology. These form taps generate up to 50% less torque versus other forming taps, making it feasible to tap materials up to 40 HRC and sizes up to or exceeding 1" in diameter
- Fluteless Forming Tap Produces no chips, making it up to 17X more durable than cut taps
- 40-50% less machining torque Longer life at faster speeds and the ability to use larger forming taps
- Coolant-fed version also available (S-XPF) For those with coolant-fed spindles, even more performance can be achieved
- DIN Overall Length Additional length provides greater reach capabilities..
Application:Aluminum Alloy, Cast Aluminum, Carbon Steels, Alloy Steel, Die Steel, Stainless Steel, Hardened Steel < 40 HRC.Higher performance with XPF is achieved when running at higher SFM.Forming is possible in Nickel Alloys such as Inconel 718 for thread sizes under 1/4"
OSG 1615012141 Thread Size M12x1.50 | Thread Limit D11 | Chamfer 4.5P | V Coated | HSS-CO | Thread Forming Tap
