SUMITOMO

Sumitomo Electric Carbide U100212 Mill Diameter 3/8 in, Number of Flutes 4, Length of Cut 3/4 in, Ball End Mill

SUMI U100212
$57.62 / EA
Out of Stock
Image for SUMI U100212
  • Mill Diameter: 0.375 in
  • Mill Diameter - Decimal: 0.375 in
  • Mill Diameter - Fractional: 3/8 in
  • Mill Diameter - Metric: 9.525 mm
  • Number of Flutes: 4
  • Length of Cut: 0.75 in
  • Material: Carbide
  • Overall Length: 2.375 in
  • Shank Diameter: 0.375 in
  • Shank Diameter - Decimal: 0.375 in
  • Shank Diameter - Fractional: 3/8 in
  • Shank Diameter - Metric: 9.525 mm
  • Finish/Coating: TiN
  • Single or Double End: Single End
  • Helix Angle: 30 deg
  • Centercutting: Center Cutting
  • Coolant Through: No
  • Cutting Direction: Right Hand
  • Extended Reach: No
  • Flute Type: Spiral
  • Length of Cut - Decimal: 0.75 in
  • Length of Cut - Fractional: 3/4 in
  • Length of Cut - Metric: 19.05 mm
  • Nose Radius: 0.1875 in
  • Overall Length - Decimal: 2.375 in
  • Overall Length - Fractional: 2-3/8 in
  • Overall Length - Metric: 60.325 mm
  • Variable Index: No
  • Flute Direction: Right Hand
  • Variable Helix: No

Standard/Approvals:MZBI424C

Sumitomo Electric Carbide U100212 Mill Diameter 3/8 in | Number of Flutes 4 | Length of Cut 3/4 in | Carbide | 2-3/8 in | Ball End Mill
