YG-1 X-POWER PRO GM109024 Series EM109 High Performance Stub Cut Length Ball Nose End Mill, 3/8 in Dia Cutter, 3/8 in Length of Cut, 2 Flutes, 3/8 in Dia Shank, 4 in OAL, Y-Coated
YG1 GM109024
$90.88
/ EA
Out of Stock
- Mill Diameter: 0.375 in
- Mill Diameter - Decimal: 0.375 in
- Mill Diameter - Fractional: 3/8 in
- Mill Diameter - Metric: 9.525 mm
- Number of Flutes: 2
- Length of Cut: 0.375 in
- Material: Carbide
- Overall Length: 4 in
- Shank Diameter: 0.375 in
- Shank Diameter - Decimal: 0.375 in
- Shank Diameter - Fractional: 3/8 in
- Shank Diameter - Metric: 9.525 mm
- Finish/Coating: Y-Coating
- Single or Double End: Single End
- Helix Angle: 15 deg
- Centercutting: Center Cutting
- Coolant Through: No
- Cutting Direction: Right Hand
- Flute Direction: Right Hand
- Length of Cut - Decimal: 0.375 in
- Length of Cut - Fractional: 3/8 in
- Length of Cut - Metric: 9.525 mm
- Nose Radius: 3/16 in
- Overall Length - Decimal: 4 in
- Overall Length - Metric: 101.6 mm
2 Flute 15 Degree Helix Stub Cut Length Ball Nose X-Power Pro
- Deep Slotting Milling Is Possible By Reduced Neck
- High Efficiency Milling Is Possible In Deep Slotting With Projection Of End Mill Being Long.
Yg-1 Cutting Tools Gm109024 Mill Diameter 3/8 In | Number Of Flutes 2 | Length Of Cut 3/8 In | Solid Carbide | 4.0000 In | Ball End Mill
