Niagara Cutter 17014237 REM710 Extended Reach Non-Center Cutting Single End End Mill, 1 in Dia Cutter, 0.03 in Corner Radius, 6 in Length of Cut, 5 Flutes, 1 in Dia Shank, 8-1/2 in OAL, Uncoated
NIACUT 17014237
$246.75
/ EA
Out of Stock
- Mill Diameter: 1 in
- Mill Diameter - Decimal: 1 in
- Mill Diameter - Metric: 25.4 mm
- Pitch: Coarse
- Length of Cut: 6 in
- Shank Diameter: 1 in
- Shank Diameter - Decimal: 1 in
- Shank Diameter - Metric: 25.4 mm
- End Type: Square End
- Material: HSS-Co8
- Finish/Coating: Bright / Uncoated
- Overall Length: 8-1/2 in
- Centercutting: No Center Cutting
- Helix Angle: 30 deg
- Chamfer Width: 0.03 in
- Chamfer Width - Decimal: 0.03 in
- Chipbreaker: No
- Corner Radius: 0.03 in
- Cutter Diameter: 1 in
- Cutting Direction: Right Hand
- Diameter: 25.4 mm
- Diameter - Metric: 25.4 mm
- Flute Type: Spiral
- Length of Cut - Decimal: 6 in
- Length of Cut - Metric: 152.4 mm
- Number of Flutes: 5
- Overall Length - Decimal: 8.5 in
- Overall Length - Fractional: 8-1/2 in
- Overall Length - Metric: 215.9 mm
- Shank Type: Weldon Flat
- Single or Double End: Single End
- Flute Direction: Right Hand
- Variable Index: No
- Variable Helix: No
General Purpose, Profiling and Slotting
Niagara Cutter End Mill | Extended Reach Non-Center Cutting Single End | Series: REM710 | 1 in Cutter Dia | 0.03 in Corner Radius | 8-1/2 in Overall Length | 6 in Maximum Depth of Cut | 5 Flutes | Spiral Flute | 1 in Shank Dia | Right Hand Cutting | 30 deg Helix Angle | Weldon Flat Shank | ANSI Code: REM710-1.000-D6-C030.3-Z5 | ISO Code: REM7101.000D6C030.3Z5 | M42 HSS-Co 8 | Uncoated
