Niagara Cutter 17001134 Elite S545 Center Cutting High Performance Medium Length Single End Square End End Mill, 9/16 in Dia Cutter, 1-1/2 in Length of Cut, 5 Flutes, 9/16 in Dia Shank, 3-1/2 in OAL, Uncoated
NIACUT 17001134
$144.50
/ EA
Out of Stock
- Mill Diameter: 9/16 in
- Number of Flutes: 5
- Length of Cut: 1-1/2 in
- Material: Solid Carbide
- Finish/Coating: Uncoated
- Shank Diameter: 9/16 in
- Shank Diameter - Decimal: 0.5625 in
- Shank Diameter - Fractional: 9/16 in
- Shank Diameter - Metric: 14.28 mm
- Overall Length: 3-1/2 in
- Cutting Direction: Right Hand
- Helix Angle: 45 deg
- Arbor/Shank Size: 9/16 in
- Cutter Diameter: 9/16 in
- Cutter Diameter - Decimal: 0.5625 in
- Cutter Diameter - Fractional: 9/16 in
- Cutter Diameter - Metric: 14.28 mm
- Length of Cut - Fractional: 1-1/2 in
- Length Type: Medium Length
- Overall Length - Fractional: 3-1/2 in
- Series: Elite S545
- Shank Type: Cylindrical
- Flute Type: Spiral
- Type: Center Cutting;High Performance
- Finish: Uncoated
- Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications on cast iron, non-ferrous materials, plastics and other tough-to-machine materials
- Uncoated tools do not feature supportive treatments on the cutting edge, they are used at reduced speeds for general applications on non-ferrous metals
- 90 deg cutting edge
- 1.771 in L minimum clamping
- 45 deg axial rake
- 10 deg radial rake
- Ideal for peripheral finish milling in steel, stainless steel, titanium and high temperature alloys
- D - Cylindrical tool shape
- Square nose end mills (also called square end) create sharp, unrounded cuts
Peripheral Finish Milling
Niagara Cutter End Mill | Center Cutting High Performance Medium Length Single End Square End | Series: Elite S545 | 9/16 in Cutter Dia | 3-1/2 in Overall Length | 9/16 in | 1-1/2 in Maximum Depth of Cut | 5 Flutes | Spiral Flute | 9/16 in Shank Dia | Right Hand Cutting | 45 deg Helix Angle | Cylindrical Shank | ANSI Code: S545-0.563-D3-S.0-Z5 | ISO Code: S545.563D3S.0Z5 | Solid Carbide | Uncoated
