Niagara Cutter 17006189 CSD230 Center Cutting Double End Short Length Square End End Mill, 3/64 in Dia Cutter, 3/32 in Length of Cut, 2 Flutes, 1/8 in Dia Shank, 1-1/2 in OAL, TiAlN Coated
NIACUT 17006189
$24.26
/ EA
Out of Stock
- Mill Diameter: 3/64 in
- Number of Flutes: 2
- Length of Cut: 3/32 in
- Material: Solid Carbide
- Finish/Coating: TiAlN Coated
- Shank Diameter: 1/8 in
- Shank Diameter - Decimal: 0.125 in
- Shank Diameter - Fractional: 1/8 in
- Shank Diameter - Metric: 3.175 mm
- Overall Length: 1-1/2 in
- Cutting Direction: Right Hand
- Helix Angle: 30 deg
- Cutter Diameter: 3/64 in
- Cutter Diameter - Decimal: 0.04687 in
- Cutter Diameter - Fractional: 3/64 in
- Cutter Diameter - Metric: 1.19 mm
- Finish: TiAlN Coated
- Length of Cut - Fractional: 3/32 in
- Overall Length - Fractional: 1-1/2 in
- Series: CSD230
- Shank Type: Cylindrical
- Type: Center Cutting;General Purpose
- Length Type: Short Length
- Flute Type: Spiral
- Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications on cast iron, non-ferrous materials, plastics and other tough-to-machine materials
- Titanium aluminum nitride (TiAlN) has a higher hardness and oxidation temperature versus TiN and TiCN, as a result, it is particularly advantageous for higher speed operations in a variety of steel machining applications
- 90 deg cutting edge
- 30 deg axial rake
- 7 deg radial rake
- 16 deg neck
- 35 deg helix angle provides increased cutting action and chip evacuation compared to the standard 30 deg helix
- F - Step tool shape
For general machining of most materials
Niagara Cutter End Mill | Center Cutting Double End Short Length Square End | Series: CSD230 | 3/64 in Cutter Dia | 1-1/2 in Overall Length | 1/8 in | 3/32 in Maximum Depth of Cut | 2 Flutes | Spiral Flute | 1/8 in Shank Dia | Right Hand Cutting | 30 deg Helix Angle | Cylindrical Shank | ANSI Code: CSD230-0.047-XF2-S.0-Z2 | ISO Code: CSD230.047XF2S.0Z2 | Solid Carbide | TiAlN Coated
