Niagara Cutter 17004835 MBZ215 Ball End Center Cutting Single End Stub Length End Mill, 1/2 in Dia Cutter, 1/2 in Length of Cut, 2 Flutes, 1/2 in Dia Shank, 4 in OAL, AlTiN Coated
NIACUT 17004835
$274.63
/ EA
Out of Stock
- Mill Diameter: 1/2 in
- Number of Flutes: 2
- Length of Cut: 1/2 in
- Material: Solid Carbide
- Overall Length: 4 in
- Shank Diameter: 1/2 in
- Shank Diameter - Decimal: 0.5 in
- Shank Diameter - Fractional: 1/2 in
- Shank Diameter - Metric: 12.7 mm
- Helix Angle: 15 deg
- Cutter Diameter: 1/2 in
- Cutter Diameter - Decimal: 0.5 in
- Cutter Diameter - Metric: 12.7 mm
- Cutting Direction: Right Hand
- Diameter: 0.197 in
- Diameter - Decimal: 0.197 in
- Finish: AlTiN
- Length of Cut - Fractional: 1/2 in
- Series: MBZ215
- Shank Type: Cylindrical
- Type: Center Cutting
- Length Type: Stub Length
- Flute Type: Spiral
- Cutter Diameter - Fractional: 1/2 in
- Solid carbide provides better rigidity than high speed steel, it is extremely heat resistant and used for high speed applications on cast iron, non-ferrous materials, plastics and other tough-to-machine materials
- Aluminum titanium nitride (AlTiN) is one of the most abrasive-resistant and hardest of the coatings, it is commonly used for machining aircraft and aerospace material, nickel alloys, stainless steel, titanium, cast iron and carbon steel
- 90 deg cutting edge
- 1.781 in L minimum clamping
- 30 deg axial rake
- 5 deg radial rake
- 3/4 in L reach
- 0.367 in Dia neck
- 7 deg draft
- E - Neck tool shape
- Rough and finish milling of contours and complex shapes
- Ideal for milling hardened mold and die steels up to 62HRc
Milling Hardened Mold and Die Steels
Niagara Cutter End Mill | Ball End Center Cutting Single End Stub Length | Series: MBZ215 | 1/2 in Cutter Dia | 4 in Overall Length | 1/2 in | 1/2 in Maximum Depth of Cut | 2 Flutes | Spiral Flute | 1/2 in Shank Dia | Right Hand Cutting | 15 deg Helix Angle | Cylindrical Shank | ANSI Code: MBZ215-0.500-E1-B.0-Z2 | ISO Code: MBZ215.500E1B.0Z2 | Solid Carbide | AlTiN Coated
