OSG 423-2188-BN 7/32 in Mill Dia, 1/2 in LOC, 2-1/2 in OAL, 3 Flutes, Carbide, Bright, Ball End Mill
OSG 423-2188-BN
$29.62
/ EA
Out of Stock
- Mill Diameter: 0.2188 in
- Mill Diameter - Decimal: 0.2188 in
- Mill Diameter - Fractional: 7/32 in
- Mill Diameter - Metric: 5.5575 mm
- Number of Flutes: 3
- Length of Cut: 0.5 in
- Material: Carbide
- Overall Length: 2.5 in
- Shank Diameter: 0.25 in
- Shank Diameter - Decimal: 0.25 in
- Shank Diameter - Fractional: 1/4 in
- Shank Diameter - Metric: 6.35 mm
- Finish/Coating: Uncoated
- Single or Double End: Double End
- Helix Angle: 30 deg
- Centercutting: Center Cutting
- Coolant Through: No
- Cutter Diameter: 7/32 in
- Cutter Diameter - Fractional: 7/32 in
- Cutting Direction: Right Hand
- Diameter: 7/32 in
- Diameter - Decimal: 0.21875 in
- End Type: Ball Nose
- Finish: Bright
- Length of Cut - Decimal: 0.5 in
- Length of Cut - Fractional: 1/2 in
- Length of Cut - Metric: 12.7 mm
- Length Type: Stub Length
- Overall Length - Decimal: 2.5 in
- Overall Length - Fractional: 2-1/2 in
- Series: 423BN
- Flute Type: Spiral
- Diameter - Fractional: 7/32 in
- Shank Type: Straight
- Diameter - Metric: 5.556 mm
- Flute Direction: Right Hand
The Standard Carbide End Mill Lineup Consists Of A Variety Of Different End Mill Designs, Made To Osg Quality Standards At A Value-Added Price Point That Is Friendly To Any Tooling Budget. An Economical Solution Without Sacrificing Consistent Tolerancing And Precision.
Application:Cast Iron, Carbon Steels, Alloy Steel, Die Steel, Stainless Steel, Hardened Steel < 45 Hrc.
Osg 423-2188-Bn Mill Diameter 7/32 In | Number Of Flutes 3 | Length Of Cut 1/2 In | Carbide | 2-1/2 In | Ball End Mill
