Seco 02505931 Indexable Drill Insert, ANSI Code: SPMX0602AP-75 F40M, Squared Shape, 0602 Insert, SPMX Insert, 2.4 mm THK, 6.4 mm Inscribed Circle, For Use On Super Alloys, Manufacturer's Grade: F40M
SECO 02505931
$23.12
/ Order multiples of 10 EA
Out of Stock
- Chipbreaker: 75
- Coating: TiAlN/TiN
- Coating Process: PVD
- Finish/Coating: PVD-TiAlN+TiN Coated
- Included Angle: 90 deg
- Inscribed Circle: 0.2500 in
- Inscribed Circle - Metric: 6.4 mm
- Insert Size: 602
- Insert Style: SPMX
- ISO Number: SPMX 0602AP-75
- Manufacturer Grade: F40M
- Manufacturer's Grade: F40M
- Material: Carbide
- Part Number: 23977
- Primary Workpiece Material: Universal
- Rake: Positive
- Relief Angle: 11 Degree
- Shape: Squared
- Thickness: 2.4 in
- PVD-coated grade for fi ne to medium rough milling
- First choice for milling with small feeds and/or low cutting speeds
- Excellent for milling when there is a risk of vibrations and when coolant is used
For machining super alloys
Seco Indexable Drill Insert | SPMX Insert | 0602 Insert | Square Shape | 6.4 mm Inscribed Circle | 2.4 mm Thickness | 6.4 mm Length | 75 Chipbreaker | Manufacturer's Grade: F40M | 90 deg Included Angle | ANSI Code: SPMX0602AP-75 F40M | For Use On: Super Alloys | Carbide | PVD-TiAlN+TiN Coated
