Seco 74016175 Indexable Drill Insert, ANSI Code: SPMX0903AP-75 T25M, Squared Shape, Material Grade: C5, 0903 Insert, SPMX Insert, 3.2 mm THK, 9.5 mm Inscribed Circle, Manufacturer's Grade: T25M
SECO 74016175
$29.64
/ EA
Out of Stock
- Chipbreaker: 75
- Coating: TiCN/TiC/TiCN/TiN
- Coating Process: CVD
- Inscribed Circle: 0.3750 in
- Insert Style: SPMX
- ISO Number: SPMX0903AP-75
- Manufacturer Grade: T25M
- Part Number: 42946
- Rake: Neutral
- Relief Angle: 11 Degree
- Width: 0.3750 in
- Material: Carbide
Seco Indexable Drill Insert | SPMX Insert | 0903 Insert | Square Shape | 9.5 mm Inscribed Circle | 3.2 mm Thickness | 9.5 mm Length | 75 Chipbreaker | Manufacturer's Grade: T25M | 90 deg Included Angle | ANSI Code: SPMX0903AP-75 T25M | Carbide | CVD-TiCN Coated | Material Grade: C5
