Seco 74016732 Indexable Drill Insert, ANSI Code: SPMX070304-75 T25M, Squared Shape, Material Grade: C5, 070304 Insert, SPMX Insert, 3.2 mm THK, 7.9 mm Inscribed Circle, Manufacturer's Grade: T25M
SECO 74016732
$20.58
/ Order multiples of 10 EA
Out of Stock
- Chipbreaker: 75
- Coating: TiCN/TiC/TiCN/TiN
- Coating Process: CVD
- Corner Radius: 0.4 in
- Finish/Coating: CVD-TiCN Coated
- Hole Diameter - Decimal: 0.0150 in
- Included Angle: 90 deg
- Inscribed Circle: 0.3130 in
- Inscribed Circle - Metric: 7.9 mm
- Insert Size: 070304
- Insert Style: SPMX
- ISO Number: SPMX070304-75
- Manufacturer Grade: T25M
- Manufacturer's Grade: T25M
- Material Grade: C5
- Part Number: 16732
- Rake: Positive
- Relief Angle: 11 Degree
- Shape: Squared
- Thickness: 3.2 in
- Material: Carbide
Seco Indexable Drill Insert | SPMX Insert | 070304 Insert | Square Shape | 7.9 mm Inscribed Circle | 3.2 mm Thickness | 7.9 mm Length | 75 Chipbreaker | 0.4 mm Corner Radius | Manufacturer's Grade: T25M | 90 deg Included Angle | ANSI Code: SPMX070304-75 T25M | Carbide | CVD-TiCN Coated | Material Grade: C5
