Seco 74016733 Indexable Drill Insert, ANSI Code: SPMX060204-75 T25M, Squared Shape, Material Grade: C5, 060204 Insert, SPMX Insert, 2.4 mm THK, 6.4 mm Inscribed Circle, Manufacturer's Grade: T25M
SECO 74016733
$19.48
/ Order multiples of 10 EA
Out of Stock
- Chipbreaker: 75
- Coating: TiCN/TiC/TiCN/TiN
- Coating Process: CVD
- Corner Radius: 0.4 in
- Finish/Coating: CVD-TiCN Coated
- Hole Diameter - Decimal: 0.0150 in
- Included Angle: 90 deg
- Inscribed Circle: 0.2500 in
- Inscribed Circle - Metric: 6.4 mm
- Insert Size: 060204
- Insert Style: SPMX
- ISO Number: SPMX060204-75
- Manufacturer Grade: T25M
- Manufacturer's Grade: T25M
- Material Grade: C5
- Part Number: 16733
- Rake: Positive
- Relief Angle: 11 Degree
- Shape: Squared
- Thickness: 2.4 in
- Width: 0.2500 in
- Material: Carbide
Seco Indexable Drill Insert | SPMX Insert | 060204 Insert | Square Shape | 6.4 mm Inscribed Circle | 2.4 mm Thickness | 6.4 mm Length | 75 Chipbreaker | 0.4 mm Corner Radius | Manufacturer's Grade: T25M | 90 deg Included Angle | ANSI Code: SPMX060204-75 T25M | Carbide | CVD-TiCN Coated | Material Grade: C5
