Seco 00085475 Milling Insert, ANSI Code: CCMX08T308T-M08 F40M, CCMX Insert, 08T308 Insert, Carbide, Manufacturer's Grade: F40M, Diamond Shape, Material Grade: C5
SECO 00085475
$25.23
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: PVD-TiAlN/NbN Coated
- Insert Size: 08T308
- Material: Carbide
- Material Grade: C5
- Insert Style: CCMX
- Manufacturer's Grade: F40M
- Length: 8.030 mm
- Inscribed Circle: 8.030 mm
- Thickness: 4.4 in
- ANSI Number: CCMX08T308T-M08 F40M
- Chipbreaker: M08
- Coating: TiAlN/NbN
- Coating Process: PVD
- Corner Radius: 0.8 in
- Hand of Insert: Right
- Included Angle: 80 Degree
- Inscribed Circle - Metric: 8 mm
- Insert Hand: Right Hand
- ISO Number: CCMX08T308T-M08 F40M
- Manufacturer Grade: F40M
- Part Number: 85475
- Primary Workpiece Material: Steel; Stainless Steel; Non Ferrous Metal; Super Alloy and Titanium; Hard Material
- Relief Angle: 7 Degree
- Shape: Diamond
Standard/Approvals:CCMX08T308T-M08 F40M
Seco Tools 85475 CCMX | 08T308 | Carbide | F40M | TiAlN/NbN | Milling Insert
