Seco 00096257 Thread Mill Insert, ANSI Code: 396.19-4005.0N5UN F30M, 396.19 Insert, 5 TPI, Internal Thread, UN Thread, Left Hand/Right Hand Cutting, Manufacturer's Grade: F30M, Material Grade: H, M, P
SECO 00096257
$264.60
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Size: 4005
- Material: Carbide
- Material Grade: H, M, P
- Manufacturer's Grade: F30M
- Thickness: 4.85 in
- Corner Radius: 0.36 in
- Cutting Direction: Left Hand/Right Hand
- Included Angle: 60 deg
- Thread Standard: UN
- Thread Type: Internal
- Threads per Inch: 5
For milling stainless steel, hardened steel and super alloys
Seco Thread Mill Insert | 396.19 Insert | 4005 Insert | Internal Thread | UN Thread Standard | 5 TPI Threads per Inch | 4.85 mm Thickness | 40 mm Length | ANSI Code: 396.19-4005.0N5UN F30M | ISO Code: 396.19-4005.0N5UN F30M | 0.36 mm Corner Radius | 60 deg Included Angle | Manufacturer's Grade: F30M | Left/Right Hand Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: H | M | P
