Seco 02505796 Milling Insert, ANSI Code: ABER2606ZFFR-M15 T350M, ABER Insert, 2606 Insert, Carbide, Manufacturer's Grade: T350M, Parallelogram Shape, Material Grade: C5
SECO 02505796
$60.57
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Size: 2606
- Material: Carbide
- Material Grade: C5
- Insert Style: ABER
- Manufacturer's Grade: T350M
- Length: 25.600 mm
- Thickness: 6.35 in
- ANSI Number: ABER2606ZFFR-M15 T350M
- Chipbreaker: M15
- Coating: TiCN+Al2O3
- Coating Process: CVD
- Corner Radius: 1.600 mm
- Corner Radius - Metric: 1.6 mm
- Hand of Insert: Right
- Insert Hand: Right Hand
- ISO Number: ABER2606ZFFR-M15 T350M
- Manufacturer Grade: T350M
- Part Number: 23907
- Primary Workpiece Material: Steel; Stainless Steel; Super Alloy and Titanium; Hard Material
- Rake: Positive
- Relief Angle: 5 Degree
- Shape: Parallelogram
Standard/Approvals:ABER2606ZFFR-M15 T350M
Seco Tools 23907 ABER | 2606 | Carbide | T350M | TiCN+Al2O3 | Milling Insert
