Seco 02509350 SNHQ Threaded Mill Insert, SNHQ Insert, 120540 Insert, Carbide, Manufacturer's Grade: F40M
SECO 02509350
$51.63
/ Order multiples of 10 EA
Out of Stock
- Insert Size: 120540
- Material: Carbide
- Insert Style: SNHQ
- Manufacturer's Grade: F40M
- Length: 5.400 mm
- Inscribed Circle: 12.700 mm
- Thickness: 0.18 in
- ANSI Number: SNHQ120540EL2-M07 F40M
- Coating: TiAlN+TiN
- Coating Process: PVD
- Corner Radius: 4.000 mm
- Corner Radius - Metric: 4 mm
- Hand of Insert: Left
- Inscribed Circle - Metric: 12.7 mm
- Insert Hand: Left Hand
- ISO Number: SNHQ120540EL2-M07 F40M
- Manufacturer Grade: F40M
- Part Number: 15985
- Primary Workpiece Material: Steel; Stainless Steel; Non Ferrous Metal; Super Alloy and Titanium; Hard Material
- Rake: Positive
- Relief Angle: 0 Degree
- Shape: Square
Standard/Approvals:SNHQ120540EL2-M07 F40M
Seco Tools 15985 SNHQ | 120540 | Carbide | F40M | TiAlN+TiN | Milling Insert
