Seco 02526611 Type Q Milling Insert, ANSI Code: SNHQ120402TL4-M07 F40M, SNHQ Insert, 120402 Insert, Carbide, Manufacturer's Grade: F40M, Squared Shape
SECO 02526611
$49.01
/ EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Size: 120402
- Material: Carbide
- Insert Style: SNHQ
- Manufacturer's Grade: F40M
- Inscribed Circle: 0.5000 in
- Thickness: 4.76 in
- Chipbreaker: M07
- Coating: TiAlN/TiN
- Coating Process: PVD
- Corner Radius: 0.2 in
- Hand of Insert: Left
- Hole Diameter - Decimal: 0.0080 in
- Included Angle: 90 Degree
- Inscribed Circle - Metric: 12.7 mm
- Insert Hand: Left Hand
- ISO Number: SNHQ120402TL4 M07
- Length of Cut: 3.650 mm
- Manufacturer Grade: F40M
- Part Number: 26311
- Primary Workpiece Material: Universal
- Rake: Positive
- Relief Angle: 0 Degree
- Shape: Squared
- Width - Metric: 12.7 mm
Standard/Approvals:SNHQ120402TL4 M07
Seco Tools 26311 SNHQ | 120402 | Carbide | F40M | TiAlN/TiN | Milling Insert
