Seco 74068059 Milling Insert, ANSI Code: 335.18-1305T-M11 F40M, 335.18 Insert, 1305 Insert, Carbide, Manufacturer's Grade: F40M, Parallelogram Shape
SECO 74068059
$50.86
/ EA
Out of Stock
- Finish/Coating: PVD-TiAlN/NbN Coated
- Insert Size: 1305
- Material: Carbide
- Insert Style: 335.18
- Manufacturer's Grade: F40M
- Width: 0.500 mm
- Length: 12.700 mm
- Inscribed Circle: 0.394 in
- Thickness: 5.4 in
- ANSI Number: 335.18-1305T-M11 F40M
- Chipbreaker: M11
- Coating: TiAlN/NbN
- Coating Process: PVD
- Corner Radius: 0.8 in
- Hand of Insert: Right/Left
- Insert Hand: Neutral
- ISO Number: 335.18-1305T-M11 F40M
- Manufacturer Grade: F40M
- Part Number: 68059
- Primary Workpiece Material: Steel; Stainless Steel; Non Ferrous Metal; Super Alloy and Titanium; Hard Material
- Rake: Positive
- Relief Angle: 0 Degree
- Shape: Parallelogram
Standard/Approvals:335.18-1305T-M11 F40M
Seco Tools 68059 335.18 | 1305 | Carbide | F40M | TiAlN/NbN | Milling Insert
