Walter 5021894 APHT0903PPR-K88 WXN15 Milling Insert PVD
WALTER 5021894
$33.49
/ Order multiples of 10 EA
Out of Stock
- Insert Size: 0903
- Material: Solid Carbide
- Material Grade: WXN15
- Insert Style: APHT
- Width: 6.750 mm
- Length: 9.520 mm
- Inscribed Circle: 6.750 mm
- Thickness: 3.180 mm
- ANSI Number: APHT0903PPR-K88 WXN15
- Chipbreaker: K88
- Clearance Angle: 11 deg
- Coating: TiCN
- Coating Process: PVD
- Corner Facet Length: 0.059 in
- Corner Radius: 0.400 mm
- Cutting Edge Length: 0.375 in
- Finish: PVD
- Hole Diameter - Metric: 2.800 mm
- Included Angle: 85 Degree
- Inscribed Circle Size: 0.266 in
- Insert Hand: Right Hand
- ISO Number: APHT0903PPR-K88 WXN15
- Manufacturer Grade: WXN15
- Mounting Hole Diameter - Decimal: 0.11 in
- Mounting Hole Diameter - Metric: 2.794 mm
- Part Number: 5021894
- Rake: Positive
- Relief Angle: 11 Degree
- Shape: Parallelogram
- K88 Geometry - The sharp one
- For machining aluminum
- Low cutting force
- Sharp cutting edges
- Three waves on the flank face
- +/-0.013 mm cutting edge tolerance
- +/-0.013 mm inscribed circle tolerance
- +/-0.025 mm thickness tolerance
- 1.2 mm width face chamfer
- 2 cutting edges
- 40 to 60 deg double countersink hole
- 90 deg approach
Standard/Approvals:WXN15, APHT0903PPR-K88 WXN15
Walter USA 5021894 APHT | 0903 | Solid Carbide | WXN15 | TiCN | Milling Insert
