Seco 00023793 Minimaster™ Milling Tip Insert, ANSI Code: MM12-0.630-D4520P-M02 F15M, MM12 Milling Tip Style, Chamfer Mill Milling Tip, Solid Carbide, Manufacturer's Grade: F15M, 2 Flutes
SECO 00023793
$192.24
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Series: Minimaster
- Milling Tip Style: MM12
- Milling Tip Type: Chamfer Mill
- Material: Solid Carbide
- Cutting Diameter - Decimal: 0.6300 in
- Cutting Diameter - Metric: 16 mm
- Manufacturer's Grade: F15M
- Depth of Cut: 0.2950 in
- Chamfer Angle: 0 Degree
- Chipbreaker: M02
- Coating: Uncoated
- Coating Process: PVD
- Geometry: M02
- Included Angle: 45 Degree
- Lead Angle: 0 Degree
- Manufacturer Grade: F15M
- Maximum Depth of Cut: 7.5 in
- Milling Tip Full Description: Double Chamfer
- Number of Flutes: 2
- Part Number: 23793
Seco Milling Tip Insert | Series: Minimaster | MM12 Milling Tip | Chamfer Mill Milling Tip | 16 mm Diameter Cutting | 7.5 mm Maximum Depth of Cut | 2 Flutes | M02 Geometry | Manufacturer's Grade: F15M | ANSI Code: MM12-0.630-D4520P-M02 F15M | ISO Code: MM12-16016-D4520P-M02 F15M | Solid Carbide | PVD-TiAlN+TiN Coated
