Seco 74034266 Minimaster™ Milling Tip Insert, ANSI Code: MM10-0.375-M03 T60M, MM10 Milling Tip Style, End Mill Milling Tip, Solid Carbide, Manufacturer's Grade: T60M, 2 Flutes
SECO 74034266
$71.00
/ EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Series: Minimaster
- Milling Tip Style: MM10
- Milling Tip Type: End Mill
- Material: Solid Carbide
- Cutting Diameter: 9.5 in
- Cutting Diameter - Decimal: 0.3750 in
- Cutting Diameter - Metric: 9.530 mm
- Material Grade: C5
- Manufacturer's Grade: T60M
- Depth of Cut: 0.2700 in
- Chamfer Angle: 6 Degree
- Chipbreaker: M03
- Coating: Coated; TiAlN/TiN
- Coating Process: PVD
- Corner Radius: 0.000 mm
- Geometry: M03
- Helix Angle: 0 Degree
- Included Angle: 90 Degree
- Lead Angle: 0 Degree
- Manufacturer Grade: T60M
- Maximum Depth of Cut: 6.8 in
- Milling Tip Full Description: Slot/Square Shoulder Milling
- Number of Flutes: 2
- Part Number: 34266
- Style: MM10-0.375-M03
Slot Milling and Square Shoulder Milling
Seco Milling Tip Insert | Series: Minimaster | MM10 Milling Tip | End Mill Milling Tip | 9.5 mm Diameter Cutting | 6.8 mm Maximum Depth of Cut | 2 Flutes | M03 Geometry | Manufacturer's Grade: T60M | ANSI Code: MM10-0.375-M03 T60M | ISO Code: MM10-09510-M03 T60M | Solid Carbide | PVD-TiAlN+TiN Coated
