Seco 74080703 Minimaster™ Milling Tip Insert, ANSI Code: MM06-0.236-M02 T60M, MM06 Milling Tip Style, End Mill Milling Tip, Solid Carbide, Manufacturer's Grade: T60M, 2 Flutes
SECO 74080703
$57.56
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Series: Minimaster
- Milling Tip Style: MM06
- Milling Tip Type: End Mill
- Material: Solid Carbide
- Cutting Diameter: 6 in
- Cutting Diameter - Decimal: 0.2360 in
- Cutting Diameter - Metric: 6.000 mm
- Manufacturer's Grade: T60M
- Depth of Cut: 0.1610 in
- Chamfer Angle: 6 Degree
- Chipbreaker: M02
- Coating: Coated; TiAlN/TiN
- Coating Process: PVD
- Corner Radius: 0.000 mm
- Geometry: M02
- Helix Angle: 0 Degree
- Included Angle: 90 Degree
- Lead Angle: 0 Degree
- Manufacturer Grade: T60M
- Maximum Depth of Cut: 4.1 in
- Milling Tip Full Description: Slot/Square Shoulder Milling
- Number of Flutes: 2
- Part Number: 80703
Slot Milling and Square Shoulder Milling
Seco Milling Tip Insert | Series: Minimaster | MM06 Milling Tip | End Mill Milling Tip | 6 mm Diameter Cutting | 4.1 mm Maximum Depth of Cut | 2 Flutes | M02 Geometry | Manufacturer's Grade: T60M | ANSI Code: MM06-0.236-M02 T60M | ISO Code: MM06-06004-M02 T60M | Solid Carbide | PVD-TiAlN+TiN Coated
