Seco 02410955 Mini-Shaft™ Threading Insert, ANSI Code: LCEX0804-G60R CP500, LCEX Insert, 20 to 16 TPI, Internal Thread, 60 deg Partial Profile Thread, 1.25 to 1.75 mm Pitch, Right Hand Cutting, Manufacturer's Grade: CP500, Material Grade: M
SECO 02410955
$45.83
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Style: LCEX
- Insert Size: 8
- Thread Standard: 60 deg Partial Profile
- Manufacturer's Grade: CP500
- Material Grade: M
- Material: Carbide
- Clearance Angle: 7 deg Front
- Corner Radius: 0.12 in
- Cutting Direction: Right Hand
- Finish: PVD
- Included Angle: 60 deg
- Length: 0.306 in
- Pitch: 1.25 to 1.75 in
- Product Name: Threading Insert
- Shape: L
- Thickness: 3.3 in
- Thread Type: Internal
- Threads per Inch: 20 to 16
- Type: Mini Shaft
Seco Threading Insert | Series: Mini-Shaft | LCEX Insert | 08 Insert | Internal Thread | 60 deg Partial Profile Thread Standard | 1.25 to 1.75 mm Pitch | 20 to 16 TPI Threads per Inch | 3.3 mm Thickness | 7.8 mm Length | ANSI Code: LCEX0804-G60R CP500 | ISO Code: LCEX0804-G60R CP500 | 0.12 mm Corner Radius | 60 deg Included Angle | Manufacturer's Grade: CP500 | Right Hand Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: M
