Seco Secomax™ 02454928 Turning Insert, ANSI Code: SCGW32.52S-00420-LF CBN200, SCGW Insert, Material Grade: K, 09T308 Insert, Squared Shape, 09 Seat, Neutral Rake, For Use On Cast Iron, PCBN, Manufacturer's Grade: CBN200
SECO 02454928
$248.40
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: Uncoated
- Insert Size: 09T308
- Material: PCBN
- Thickness: 3.97 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: CBN200
- Chipbreaker: LF
- Hole Diameter - Metric: 4.5 mm
- Included Angle: 90 deg
- Inscribed Circle - Metric: 9.52 mm
- Material Grade: K
- Maximum Depth of Cut: 3.75 in
- Rake: Neutral
- Relief Angle: 7 deg
- Seat Size: 09
- Shape: Squared
- Width - Metric: 9.52 mm
- When turning internally or machining slender components, you can rely on the super sharp cutting edges of CoroTurn® 107
- The low cutting forces and precision coolant combined with a broad range of inserts ensures high quality surface finish
- Wiper geometries available for high feeds and high quality surface finish
- Ground, super sharp insert offer for exceptional surface finish
- 40 to 60 deg countersunk hole and non-flat surface
Seco Secomax Turning Insert | SCGW Insert | 09T308 Insert | Square Shape | 3.75 mm Maximum Depth of Cut | 9.52 mm Inscribed Circle | 3.97 mm Thickness | 9.52 mm Width | 9.52 mm Length | 09 Seat | Neutral Rake | LF Chipbreaker | 0.8 mm Corner Radius | 4.5 mm Diameter Hole | Manufacturer's Grade: CBN200 | ANSI Code: SCGW32.52S-00420-LF CBN200 | ISO Code: SCGW09T308S-01020-LF CBN200 | 90 deg Included Angle | 7 deg Relief Angle | PCBN | Uncoated | Material Grade: K | For Use On: Cast Iron
