Seco 02959896 Turning Insert, ANSI Code: DNMG444-M6 TP1501, DNMG Insert, Material Grade: P, 150616 Insert, Diamond Shape, 15 Seat, Negative Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP1501
SECO 02959896
$31.24
/ EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: DNMG
- Insert Size: 150616
- Material: Carbide
- Length: 15 mm
- Thickness: 6.35 in
- Corner Radius: 1.6 mm
- Manufacturer's Grade: TP1501
- Chipbreaker: M6
- Corner Radius - Metric: 1.6 mm
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Decimal: 0.20275 in
- Hole Diameter - Metric: 5.15 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 12.7 mm
- Inscribed Circle Size: 12.7 mm
- Material Grade: P
- Maximum Depth of Cut: 5.25 in
- Rake: Negative
- Relief Angle: 0 deg
- Seat Size: 15
- Shape: Diamond
- Type: Negative;Basic Shape
- Width: 15 mm
INSERT DNMG444-M6 TP1501
