Seco 02960843 Turning Insert, ANSI Code: CCMT21.51-FF1 TP2501, CCMT Insert, Material Grade: P, 060204 Insert, Diamond Shape, 06 Seat, Negative/Positive Rake, Neutral Cutting, For Use On Steel, Carbide, Manufacturer's Grade: TP2501
SECO 02960843
$15.57
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: CVD-TiCN+Al2O3 Coated
- Insert Style: CCMT
- Insert Size: 060204
- Material: Carbide
- Inscribed Circle: 6.350 mm
- Thickness: 2.38 in
- Corner Radius: 0.4 in
- Manufacturer's Grade: TP2501
- Chipbreaker: FF1
- Coating: TiCN/Al2O3
- Coating Process: CVD
- Cutting Direction: Neutral
- Finish: CVD
- Hole Diameter - Metric: 2.9 mm
- Included Angle: 80 deg
- Inscribed Circle - Metric: 6.4 mm
- Inscribed Circle Size: 6.35 mm
- Insert Hand: Neutral
- ISO Number: CCMT060204-FF1 TP2501
- Manufacturer Grade: TP2501
- Material Grade: P
- Maximum Depth of Cut: 2.5 in
- Overall Length: 6.500 mm
- Part Number: 19404
- Primary Workpiece Material: Steel; Stainless Steel; Cast Iron
- Rake: Negative/Positive
- Relief Angle: 7 deg
- Seat Size: 06
- Shape: Diamond
- Type: Basic Shape;Positive
Standard/Approvals:CCMT060204-FF1 TP2501
Seco Tools 19404 CCMT | 21.51 | FF1 | TP2501 | Carbide | Turning Insert
