Seco 02688996 R217.69 Indexable Square-Shoulder End Mill, 1.5 in Dia Cutting, Weldon Shank, 90 deg Lead Angle, 0.433 in Max Depth of Cut
SECO 02688996
$775.20
/ EA
Out of Stock
- Cutting Diameter: 1.5 in
- Cutting Diameter - Metric: 38.1 mm
- Shank Type: Weldon
- Shank Diameter: 1.25 in
- Shank Diameter - Metric: 38.1 mm
- Overall Length/Projection: 121.400 mm
- Lead Angle: 90 deg
- Through Coolant: Non-Through Coolant
- Coolant Through: Yes
- End Mill Type: Cylindrical
- Insert Holding Method: Right Hand
- Length of Cut: 0.625 in
- Maximum Depth of Cut: 0.433 in
- Maximum RPM: 16400 RPM
- Overall Length: 4.78 in
- Part Number: 52543
- Shank Length: 2.441 in
- Toolholder Material: Solid Carbide
CUTTER R217.69-01.50-3S-12-5AN
