Techniks 6275370 Size 500.00 mm, 14.5670 in Min Dia, 14.5670 in Min Dia, Modular Boring Cutting Unit Head
TECHNK 6275370
$5,533.92
/ EA
Out of Stock
- Minimum Bore Diameter: 14.567 in
- Body Diameter - Metric: 352 mm
- Connection Diameter - Metric: 60 mm
- Insert Holder: TCMT 325
- Maximum Bore Diameter: 19.685 in
- Projection Length: 3.54 in
- Weight: 1
75˚ Finishing Heads feature AccuSET graduated dial for fast and easy cutting adjustments in 0.0001″ increments. 75˚ lead angle head tends to self-center in the pilot hole, stabilizing the cut and maximizing stock removal rates. Roughing and Finishing heads are available in 75° and 90° lead angles for both through bores and blind bores.
- AccuSET slide includes graduated dial for fast adjustments in 0.0001 in increments
- Manufactured from top quality steel alloy, hardened to 58 to 60 HRc to minimize wear
- Two offset center lock screws maximize rigidity while still permitting fast tool changes
- 75 Degree lead angle heads tend to self center in the pilot hole, stabilizing the cut and maximizing stock removal rates
Techniks 6275370 Size 500.00 mm | 14.5670 in Min Dia | 14.5670 in Min Dia, | 3.5400 in | TCMT 325 | Modular Boring Cutting Unit Head
