Dataflute CNC
DATCNC 40283-00-D in Milling Dia, in LOC, in OAL, Flutes, , , Roughing & Finishing End Mills
DATCNC 40283-00-D
$24.99
/ EA
Out of Stock
- Mill Diameter: 0.25 in
- Mill Diameter - Decimal: 0.25 in
- Mill Diameter - Fractional: 1/4 in
- Mill Diameter - Metric: 6.35 mm
- Number of Flutes: 5
- Material: Carbide
- Finish/Coating: Uncoated
- Length of Cut: 0.375 in
- Shank Diameter: 0.25 in
- Shank Diameter - Decimal: 0.25 in
- Shank Diameter - Fractional: 1/4 in
- Shank Diameter - Metric: 6.35 mm
- Overall Length: 2 in
- Flute Direction: Right Hand
- Length of Cut - Decimal: 0.375 in
- Length of Cut - Fractional: 3/8 in
- Length of Cut - Metric: 9.525 mm
- Overall Length - Decimal: 2 in
- Overall Length - Metric: 50.8 mm
- Part Number: 40283-00-D
- Flute Type: Spiral
Our MH series is the tool of choice for finishing and light profile roughing in ferrous materials. The odd number of flutes disrupts unwanted harmonics. Our medium helix provides an optimum shear angle to aid chip evacuation. We have a full offering of stub, standard, medium, long and extra long lengths of cut.
- High Performance Carbide
- Eccentric Primary
- 45 Degree Helix
- Available in Stub, Standard,
- Medium, Long and Extra Long
Dataflute CNC 40283-00-D | 5 | Roughing & Finishing End Mill
