Guhring 9055370043900 0.1730 in, 118 Degree, Parabolic, Taper Length Drill Bit

GUH 9055370043900
$38.14 / Order multiples of 10 EA
Out of Stock
Image for GUH 9055370043900
  • Cutting Direction: Neutral
  • Shank Type: Straight
  • Corner Radius: 0.4 in
  • Finish: CVD
  • Finish/Coating: CVD-TiCN+Al2O3 Coated
  • Flute Length: 82.00 mm
  • Flute Type: Parabolic
  • Helix Angle: 30 deg
  • Included Angle: 60 deg
  • Inscribed Circle - Metric: 9.52 mm
  • Insert Size: 160304
  • Length: 0.649 in
  • Manufacturer's Grade: TP2501
  • Material: Carbide
  • Material Grade: P
  • Maximum Depth of Cut: 3.75 in
  • Overall Length: 126.00 mm, 2-1/2 in
  • Point Type: 4-Facet; Split Point
  • Relief Angle: 11 deg
  • Seat Size: 16
  • Series: 150
  • Shank Diameter - Fractional: 3/16 in
  • Shank Diameter - Metric: 4.39 mm
  • Shape: Triangular
  • Thickness: 3.18 in
  • Diameter - Metric: 4.762 mm
  • Shank Diameter - Decimal: 0.1875 in
  • Titanium nitride (TiN) is a multi-purpose coating that increases chip flow in softer materials, the heat and hardness resistance allows the tool to run at higher speeds than uncoated tools
  • Increased wear-resistancespiral flutes are constructed with a higher flute angle to remove chips more easily
  • H8 tolerance on cut/shank diameter
  • 23 mm L shank
  • External coolant

Standard/Approvals:DIN 340

Application:

  • Cobalt is harder than high speed steel and provides better wear resistance, it is commonly used on high tensile alloys

    • Guhring 9055370043900 0.1730 in | 118 Degree | Parabolic | HSCO | TiN | Taper Length Drill Bit
