Niagara Cutter Stabilizer™ 2.0 03084130 Stabilizer™ 2.0 STR440.2 Center Cutting High Performance Single End Stub Length End Mill, 1/8 in Dia Cutter, 0.01 in Corner Radius, 1/8 in Length of Cut, 4 Flutes, 1/8 in Dia Shank, 1-1/2 in OAL, AlTiN Coated
- Mill Diameter: 1/8 in
- Mill Diameter - Decimal: 0.125 in
- Mill Diameter - Fractional: 1/8 in
- Mill Diameter - Metric: 3.175 mm
- Corner Radius: 0.01 in
- Number of Flutes: 4
- Material: Carbide
- Length of Cut: 1/8 in
- Shank Diameter: 1/8 in
- Shank Diameter - Decimal: 0.125 in
- Shank Diameter - Fractional: 1/8 in
- Shank Diameter - Metric: 3.175 mm
- Overall Length: 1-1/2 in
- Cutting Direction: Right Hand
- Helix Angle: 40 deg
- Variable Index: No
- Centercutting: Center Cutting
- Chipbreaker: No
- Corner Radius - Decimal: 0.01 in
- Cutter Diameter: 1/8 in
- End Type: Corner Radius
- Finish/Coating: AlTiN
- Flute Type: Spiral
- Length of Cut - Decimal: 0.125 in
- Length of Cut - Fractional: 1/8 in
- Length of Cut - Metric: 3.175 mm
- Overall Length - Decimal: 1.5 in
- Overall Length - Fractional: 1-1/2 in
- Overall Length - Metric: 38.1 mm
- Series: Stabilizer 2.0 STR440.2
- Shank Type: Cylindrical
- Single or Double End: Single End
- Type: Center Cutting;High Performance
- Variable Helix: Yes
- Cutter Diameter - Fractional: 1/8 in
- Finish: AlTiN
- Flute Direction: Right Hand
The Stabilizer™ 2.0 family of end mills raises the bar in high performance milling by incorporating a patented continuously varying asymmetrical geometry which helps create a smooth chatter free milling condition. This configuration, along with a specially engineered flute shape, allow for feed rates twice that of the current Stabilizer™. The ST430.2 series of end mills are specifically designed for machining steels, alloy steels, copper alloys and cast iron. The ST440.2 HT series of end mills are specifically designed for machining ISO-S materials such as stainless steel, steels over 42 Rc, titanium and inconel. These end mills also feature an AlTiN coating that offers high heat resistance and superior abrasion resistance to maximize tool life.
- Solid carbide high performance tools excel in slot and side milling
- Double the feed rates compared to previous Stabilizer
- Longer tool life than previous tool types even when applied at 2X the feed rates
- Continuously varying asymmetrical geometry provides smooth, chatter free cutting
- Wide application area covered, from steel to exotic materials
- Reduced cycle times with higher metal removal rates
- Minimized harmonics
- High heat and abrasion resistance
- Smooth chatter free cutting
- Long and predictable tool life
- Consistent performance in all applications
Profiling and Slotting
Niagara Cutter End Mill | Center Cutting High Performance Single End Stub Length | Series: Stabilizer 2.0 STR440.2 | 1/8 in Cutter Dia | 0.01 in Corner Radius | 1-1/2 in Overall Length | 1/8 in Maximum Depth of Cut | 4 Flutes | Spiral Flute | 1/8 in Shank Dia | Right Hand Cutting | 40 deg Helix Angle | Cylindrical Shank | ANSI Code: STR440.2-0.125-D1-R010.0-Z4 | ISO Code: STR440.2.125D1R010.0Z4 | Solid Carbide | AlTiN Coated
