OSG 3097642 1.5 mm Corner Rad, 6 mm Mill Dia, 9 mm LOC, in OAL, Flutes, , , Corner Radius & Corner Chamfer End Mill
OSG 3097642
$299.73
/ EA
Out of Stock
- Mill Diameter: 6 mm
- Number of Flutes: 3
- Material: Carbide
- Length of Cut: 9 mm
- Shank Diameter: 8 mm
- Shank Diameter - Decimal: 0.31496 in
- Shank Diameter - Metric: 8 mm
- Overall Length: 100 mm
- Cutting Direction: Right Hand
- Helix Angle: 55 deg
- Cutter Diameter: 6 mm
- Cutter Diameter - Metric: 6 mm
- Diameter: 0.23622 in
- Diameter - Decimal: 0.23622 in
- Diameter - Metric: 6 mm
- End Type: Center Cutting
- Finish: WXS® Coated
- Finish/Coating: WXS® Coated
- Length of Cut - Metric: 9 mm
- Length Type: Pencil Neck
- Neck Diameter: 5.9 - 7.33 mm
- Neck Diameter - Metric: 5.9 - 7.33 mm
- Overall Length - Metric: 100 mm
- Series: 9580
- Shank Type: Shrink Fit
- Type: Center Cutting
- Flute Type: Spiral
The EXOPRO® PHX end mill series is designed exclusively for mold makers, to help them realize greater cost savings and shorter delivery times with their existing equipment. New spiral gash geometry is combined with radial chip thinning principles to create end mills capable of taking deeper depths of cut with length to diameter ratio's previously thought impractical.
- Spiral Gash geometry Increases edge strength and reduces chip thickness
- OSG's WXS® nano coating WXS® boasts the absolute highest hardness and heat resistance of any OSG coating
- Available in a wide variety of shapes and lengths To reach any mold cavity or core.
OSG 3097642 0.2362 in Dia | 3 Flute | Carbide | 0.0591 in | WXS | Corner Radius & Corner Chamfer End Mill
