JABRO® H/Tornado 00022026 JABRO® H/Tornado JH930 Non-Center Cutting Single End Universal End Mill SM
SECO 00022026
$154.44
/ EA
Out of Stock
- Mill Diameter: 6 mm
- Mill Diameter - Metric: 6 mm
- Corner Radius: 0.2 mm
- Number of Flutes: 5
- Material: Solid Carbide
- Length of Cut: 9 mm
- Shank Diameter: 6 mm
- Shank Diameter - Metric: 6 mm
- Overall Length: 55 mm
- Cutting Direction: Right Hand
- Helix Angle: 41 deg
- Cutter Diameter: 6 in
- Finish/Coating: MEGA/PVD Coated
- Flute Direction: Right Hand
- Flute Type: Right Spiral
- Neck Diameter: 5.6 mm
- Neck Diameter - Metric: 5.6 mm
- Overall Length - Metric: 55 mm
- Part Number: 08106
- Shank Type: Cylindrical
Seco is offering you the Tornado program. Tornado is a complete range of solid carbide cutters especially developed for high speed machining. Tornado is the result of continuous research into the best possible combination of solid carbide quality, cutter geometry and coatings in relation to the material to be machined.
Radial and Ramping Applications
JABRO End Mill | Non-Center Cutting Single End Universal | Series: JABRO HSM/Tornado JH930 | 6 mm Cutter Dia | 0.2 mm Corner Radius | 55 mm Overall Length | 9 mm Maximum Depth of Cut | 5 Flutes | Right Spiral Flute | 6 mm Shank Dia | Right Hand Cutting | 41 deg Helix Angle | Cylindrical Shank | ANSI Code: 930060R020-MEGA | ISO Code: 930060R020-MEGA | Solid Carbide | MEGA/PVD Coated
