Seco 00026924 Seco-Capto™ External Multi-Directional Modular Turning Unit Head, C6 System, Left Hand Cutting, 65 mm L Head/Projection
- Insert Holding Method: Secoloc™ Clamp
- System Size: C6
- Center to Cutting Edge - Metric: 32.5 mm
- Head Length - Metric: 65 mm
The Seco MDT (multi-directional turning) is universally suitable for variety of applications including grooving, profiling, turning, parting-off and threading. The unique Secoloc™ clamping delivers the best stability and safety in addition to high productivity and performance. Applications include turning parts with many different diameters, complicated profiles and grooves, replacing the need for several standard and special tools with a single Seco MDT. Further savings can be achieved through fewer tool changes and reduced tool stock. The unique insert clamping method Secoloc™ combines a V-shaped top clamp with serrated contact surfaces between the underside of the insert and the toolholder for superb stability. The relatively long insert also increases stability.
Includes: C46017-T20P Clamp Screw, F85015-T20P Locking Screw, T20P-7L Key and CN6 Coolant Nozzle
Grooving, Profiling, Turning, Parting-Off and Threading
Seco Modular Turning Unit Head | External Multi-Directional | Series: Seco-Capto | 65 mm Head Length/Projection | System Size: C6 | Left Hand Cutting Direction | 32.5 mm Center to Cutting Edge | Secoloc Clamp Insert Holding Method
