Seco 00096260 Thread Mill Insert, ANSI Code: R396.19-4005.0X8NPT F30M, R396.19 Insert, 8 TPI, Internal/External Thread, NPT Thread, Right Hand Cutting, Manufacturer's Grade: F30M, Material Grade: H, M, P
SECO 00096260
$256.80
/ Order multiples of 2 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Size: 4005
- Material: Carbide
- Material Grade: H, M, P
- Insert Style: R396.19
- Manufacturer's Grade: F30M
- Length: 1.5750 in
- Thickness: 4.85 in
- Coating: Coated
- Coating Process: PVD
- Conical: No
- Corner Radius: 0.12 in
- Cutting Direction: Right Hand
- Included Angle: 60 deg
- Manufacturer Grade: F30M
- Part Number: 96771
- Thread Standard: NPT
- Thread Type: Internal/External
- Threads per Inch: 8
For milling stainless steel, hardened steel and super alloys
Seco Thread Mill Insert | R396.19 Insert | 4005 Insert | Internal/External Thread | NPT Thread Standard | 8 TPI Threads per Inch | 4.85 mm Thickness | 40 mm Length | ANSI Code: R396.19-4005.0X8NPT F30M | ISO Code: R396.19-4005.0X8NPT F30M | 0.12 mm Corner Radius | 60 deg Included Angle | Manufacturer's Grade: F30M | Right Hand Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: H | M | P
