Seco 00096708 Turning Insert, ANSI Code: VBMT21.51-F1 CP500, VBMT Insert, Material Grade: M, S, 110204 Insert, Diamond Shape, 11 Seat, Positive Rake, Neutral Cutting, For Use On Stainless Steel, Super Alloys and Titanium, Carbide, Manufacturer's Grade: CP500
SECO 00096708
$22.23
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Style: VBMT
- Insert Size: 110204
- Material: Carbide
- Thickness: 2.38 in
- Corner Radius: 0.4 in
- Manufacturer's Grade: CP500
- Chipbreaker: F1
- Clearance Angle: 5 deg
- Cutting Direction: Neutral
- Hole Diameter - Metric: 2.9 mm
- Included Angle: 35 deg
- Inscribed Circle - Metric: 6.35 mm
- Inscribed Circle Size: 0.25 in
- Material Grade: M, S
- Maximum Depth of Cut: 2.75 in
- Rake: Positive
- Relief Angle: 5 deg
- Screw Diameter - Decimal: 0.114 in
- Screw Diameter - Metric: 2.895 mm
- Seat Size: 11
- Shape: Diamond
INSERT VBMT21.51-F1 CP500
