Seco Feedmax™ 02500392 SD203A Shank Drill, 4.3 mm Drill - Metric, 0.1693 in Drill - Decimal Inch, Solid Carbide, PVD TiAlN+TiN Coated
SECO 02500392
$200.88
/ EA
Out of Stock
- Drill Bit Size: 0.1693 in
- Drill Bit Size - Metric: 4.3 mm
- Cutting Direction: Right Hand
- Shank Type: Whistle Notch
- Finish/Coating: PVD TiAlN+TiN Coated
- Flute Length: 24 in
- Flute Length - Metric: 24
- Material: Solid Carbide
- Number of Flutes: 2
- Overall Length - Metric: 66 mm
- Point Angle: 140 deg
- Point Type: Self-Centering
- Shank Size: 6 mm Dia x 36 mm L
- Flute Type: Spiral
Seco Feedmax™ is our latest generation of high performance solid carbide drills. They offer a unique combination of state-of-the-art carbide, coating and geometry technology.
- Chamfer drills combine drilling and chamfering into a single process to maximize efficiency
- These drills minimize cost per holes through a design that maximizes productivity
- The self-centering geometry provides high hole quality using a 45 deg (90 deg included angle) chamfer angle
- A special TiAlN coating provides high hot hardness, which combines with a strong cutting edge to ensure long and predictable tool life
Standard/Approvals: DIN 6537B
For hole making applications
Seco Feedmax Chamfer Drill | Series: SD203A | Metric | 4.3 mm Dia | 66 mm Overall Length | 3XD Cutting Depth | 2 Flutes | Spiral Flute | 24 mm Flute Length | 6 mm Dia x 36 mm L Shank | Whistle Notch Shank | 140 deg Point | Self-Centering Point | Right Hand Cutting | Solid Carbide Cutting Edge | Solid Carbide | PVD TiAlN+TiN Coated | Applicable Materials: Cast Iron | Non-Ferrous Materials and Plastics
