Seco 02615902 Turning Insert, ANSI Code: DNMP432-MF1 TS2000, DNMG Insert, Material Grade: S, 150408 Insert, Diamond Shape, 15 Seat, Negative Rake, Neutral Cutting, For Use On Super Alloys and Titanium, Carbide, Manufacturer's Grade: TS2000
SECO 02615902
$25.13
/ Order multiples of 10 EA
Out of Stock
- Finish/Coating: PVD-TiAlN+TiN Coated
- Insert Style: DNMG
- Insert Size: 150408
- Material: Carbide
- Length: 15 mm
- Thickness: 4.76 in
- Corner Radius: 0.8 in
- Manufacturer's Grade: TS2000
- Chipbreaker: MF1
- Cutting Direction: Neutral
- Finish: PVD
- Hole Diameter - Decimal: 0.20275 in
- Hole Diameter - Metric: 5.15 mm
- Included Angle: 55 deg
- Inscribed Circle - Metric: 12.7 mm
- Inscribed Circle Size: 12.7 mm
- Material Grade: S
- Maximum Depth of Cut: 5.25 in
- Rake: Negative
- Relief Angle: 0 deg
- Seat Size: 15
- Shape: Diamond
- Type: Negative;Basic Shape
- Width: 15 mm
- Reliable and secure machining, even in roughing applications
- Possibility to optimize by using damped Silent Tools™
- Excellent surface finish
Medium and Finishing
Seco Turning Insert | DNMG Insert | 150408 Insert | Diamond Shape | 5.25 mm Maximum Depth of Cut | 12.7 mm Inscribed Circle | 4.76 mm Thickness | 15 Seat | Negative Rake | MF1 Chipbreaker | 0.8 mm Corner Radius | 5.15 mm Diameter Hole | Manufacturer's Grade: TS2000 | ANSI Code: DNMP432-MF1 TS2000 | ISO Code: DNMG150408-MF1 TS2000 | 55 deg Included Angle | 0 deg Relief Angle | Neutral Cutting Direction | Carbide | PVD-TiAlN+TiN Coated | Material Grade: S | For Use On: Super Alloys and Titanium
